Arm Cup Wedges

135.45

The arm cup wedge is designed to increase support for the elbow and forearm when the high-hands time trial position is used. The wedge solution provides 15-degrees of tilt for the elbow cup. The 15-degree cup angle matches the angle of the forearm, when of 100 mm of height gain to the extremity of the extension is fully utilised.

Supporting the high-hands time trial position, improving comfort and position consistency. Our arm cup wedges allow athletes to maximise gains in aerodynamic efficiency.


Prices exclude GST for international customers once product is placed in cart.

Arm Cup Wedge:
Quantity:
Add To Cart



Supporting the high-hands time trial position, improving comfort and position consistency. Our arm cup wedges allow athletes to maximise gains in aerodynamic efficiency.



The design of the wedge solution draws on our experience gained from our position optimisation services. Kinematic analysis of optimised time trial positions has shown a consistent forearm inclination angle of 15-degrees, when the high-hands position is fully utilised. Validated in the velodrome using the Alphamantis Technologies Track Aero System, the high-hands time trial position has been shown to improve aerodynamic efficiency.

Be it for comfort or performance outcomes, the high-hands position is favored by most triathlon and time trial athletes aiming to optimise their position. The wedge solution improves position consistency through increasing pad contact with the elbow and forearm. When combined with an ergonomic elbow cup, the wedge solution allows athletes to maximise aero gains, while also improving comfort at the forearm contact point.



Product Specifications

Tilt angle - 15-degrees
Bolt spacing (cup-wedge) - 25 mm (51 Speedshop)
Bolt spacing (wedge-bar) - Variable, 25-30 mm
Mounting bolts - M5 or M6 mounting options available

Material – CNC machined aluminium
Finish - Black anodised
Wedge hardware – 10 mm, M5 or M6 button (high-tensile)
Cup hardware - 10 mm, M5 countersunk (stainless)
Weight - 66g including hardware

Adaptive HP wedges are designed to work with the 51 Speedshop cups, using the standard 25 mm bolt spacing.


M5 Wedge Compatibility

Factor Slick
Giant Trinity (2010-current)
3T Vola and Cervelo P5
Specialized Shiv TT

M6 Wedge Compatibility

Scott Plasma (with part #242123)
Profile Design (Aeria Ultimate)
ENVE SES Aero TT
Canyon CF SLX




I have worked extensively with Adaptive HP on the optimisation of my time trial position, ensuring I can maximise aero performance, while being able to produce maximum power in race conditions. Their front end time-trial parts have been crucial in achieving these goals, while also improving comfort.

James Ogilvie – UCI Masters Hour Record Holder/Masters National ITT Champion
